The female IP68 connector ensures strong locking, excellent insulation, and reliable current transmission. Designed for long-term durability in harsh environmental conditions.
The Modular Type PV Junction Box is designed for long-term durability, high current handling (up to 35A), and excellent waterproof protection (IP68). With less potting glue and flame-retardant design, it ensures safe and efficient performance.
Higher Current Carrying Capacity
Low Resistance Value
Waterproof Up to IP68
Plug & Play
| Flame Class | UL94-V0 |
| Upper Limiting Temperature | 110°C |
| Withdrawal Force | ≥50N/≤50N |
| Overvoltage Category | CATIII/2 |
| Ambient Temp Range | -40°C...+85°C(IEC) |
| Suitable Cable Cross Section | 2.5~16mm2 /14~6AWG |
| Connection Mode | Crimp Connection |
| Product Color | Black |
